$195.00
STAR-switch SP8 Exterior
IP67 robust 8-Button Switch Block: Built to withstand the toughest conditions.
Compact Design: 105x 63x 16mm. Operates STAR-light with CAN. Backlit press tactile buttons, Tri-Color LED for On/Off/Fault.
Multi-functional, optional custom engraved, buttons: single press for one channel, hold to dim. Double press to switch LED to a second color or RGBW channel.
Custom Engraving not included
STAR-switch 8 button Rugged Switch block
- 105mm x 63mm x 16mm with plug 22mm behind
- Secured by 2 x M6 bolts
- Sealed to IP67
- Wired at 12V with CAN
- Press buttons backlit (not capacitive touch)
- Rubber encapsulated surface
- Three LED indicators:
- Optional Custom Engraving*
- Press button once for one channel, hold to dim. Double press same button and LED can be switched to second color or RGBW channel.
- Deutsch plug 4 pin connector on rear
- Each button can be in parallel to 6 way switching
- Dimmable LED indicators
- Vibration and impact resistant
- Operating temp: -40oC to +85oC
- Long life: 1,000,000 cycles per key
- Support for multiple key press combinations
Compatible with new STAR-power and STAR-light:
- Dimming control of LEDs
- Double tap and switch LED color if dual color of RGBW LED’s wired to STAR-light module.
- Up to 6 switch buttons can control one STAR-light channel
*Custom Engraving the buttons is an additional fee and will be processed as a separate order. To order the custom engraving, go to the form at the bottom of this page. This is a separate ordering process to the switch itself. There are conditions for ordering which need to be read.
